Explosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio
  • Explosion Proof Dmr Mobile RadioExplosion Proof Dmr Mobile Radio

Explosion Proof Dmr Mobile Radio

We can provide professional service and better price for you. If you interested in Industrial Explosion Proof Dmr Mobile Radio, please contact with us. We follow the quality of rest assured that the price of conscience, dedicated service. Introducing our new explosion-proof DMR mobile radio designed to meet the needs of workers in hazardous working environments. This advanced mobile radio is built to withstand the harshest conditions, providing reliable communications and safety to workers in oil and gas, chemicals, mining, and other industries where explosive gases and dusts are present.

Model:M4

Send Inquiry

Product Description

One of the Chinese companies offering Explosion Proof Dmr Mobile Radio for wholesale is Lisheng. For you, we can offer better pricing and competent service. Should you be intrigued by Explosion Proof Dmr Mobile Radio, kindly get in touch with us. We adhere to the standard of conscience-driven, committed service at the cost of quality assurance.OneWe adhere to the standard of conscience-priced, devoted service, so you can feel secure. Introducing our new explosion-proof DMR mobile radio designed to meet the needs of workers in hazardous working environments. This advanced mobile radio is built to withstand the harshest conditions, providing reliable communications and safety to workers in oil and gas, chemicals, mining, and other industries where explosive gases and dusts are present.


Explosion-proof DMR mobile radios are specifically designed to comply with international standards for use in potentially explosive environments, ensuring the highest level of safety for workers in these high-risk environments. The radio has a rugged construction and is explosion-proof certified to prevent explosions from any potential ignition source.


The radio is equipped with Digital Mobile Radio (DMR) technology for seamless, clear communication between workers, supervisors and the control room. It supports private and group calls, ensuring teams can always stay connected and coordinated. DMR technology delivers superior audio quality even in noisy and harsh environments, ensuring critical information is heard and understood without interference.


In addition to rugged design and advanced communication capabilities, explosion-proof DMR mobile radios offer a range of other advantages. It is intrinsically safe, meaning it is designed to prevent the release of enough electrical or thermal energy to ignite a specific hazardous atmosphere. This level of safety is critical for workers who often work in environments where explosive materials are present.


The radio also features long-lasting battery life, ensuring workers can rely on continuous communication throughout their shift. Its ergonomic design and intuitive interface make it easy to use, even while wearing gloves or protective gear. The large, high-contrast display is designed for use in low-light conditions, making it easy to read in any environment.


Additionally, the explosion-proof DMR mobile radio comes with a range of accessories to enhance its functionality. These include a remote speaker microphone, headset and vehicle mounting kit, allowing for flexible use of the radio. These accessories are also designed to be extremely durable and resistant to the same hazardous conditions as the radio itself.


Overall, explosion-proof DMR mobile radios are critical tools for ensuring the safety and productivity of workers in hazardous environments. Its reliable communications capabilities and rugged, intrinsically safe design make it a must-have for any team working in potentially explosive environments. With this radio, workers can rest easy knowing they are equipped with the highest level of safety and communications technology.


M4 is available in both DMR Tier 2 and analog modes, it supports AES 256 encryption keys to secure communication. Rugged and Reliable, IP68 ingress protection, the radio can use across multiple environments and industries.


M4EX Intrinsically Safe version is specially designed for those who work in environments with explosive gas and combustible dusts, providing secure and reliable voice and data communication in the dangerous areas.


Product Specification:

General
Frequency Range 136~174MHz,350~400MHz
400~470MHz,450~520MHz
Channel Spacing 12.5 KHz / 25 KHz
Channel/Zone Capacity 32Channels /2 Zones
Operating Voltage 7.4V
Battery Capacity 2200mAh
Battery Life (5/5/90) Analog: 11 hours ; Digital: 14 hours
Vocoder Type AMBE+2
Frequency Stability ±1.0ppm
Antenna Impedance 50Ω
Dimensions (without Antenna) 133.5*61.7*40mm
Weight Around 300g
Ingress Protection (IP) Rating IP68


Receiver
Analog Sensitivity 0.2μV (12dB SINAD)
Digital Sensitivity 0.22μV (Typical) (BER 5%)
Adjacent Channel Selectivity 60dB @ 12.5KHz / 65dB @ 25KHz
Intermodulation Rejection 60dB @ 12.5KHz / 60dB @ 25KHz
Blocking 84dB @ 12.5KHz /84dB @ 25KHz
Co-Channel Rejection -12dB @ 12.5KHz
 -8dB @ 25KHz
Spurious Response Rejection 65dB @ 12.5KHz / 65dB @ 25KHz
Rated Audio Output Power 1.0W /16Ω
Conducted Spurious Emission <-57dBm(9KHz~1GHz)
<-47dBm(1GHz~12.75GHz)


Transmitter
RF Power 1W (Low) / ≤5W (High)
Power Margin Variation +2/-3dB (under Extreme Conditions)
Frequency  Error ±1.0ppm
FSK Error <5%
4FSK Transmission
Bit Error Rate (BER)
≤1×10-4
4FSK Modulation
Frequency Deviation Error
≤10.0%
Occupied Bandwidth (PDT/DMR) ≤8.5KHz
TX Attack/Release Time ≤1.5ms
Adjacent Channel Power ≤-50dB @12.5KHz /≤-60dB @25KHz
Transient Adjacent Channel Power ≤-50dB @ 12.5KHz / ≤-60dB @ 25KHz
FM Modulation 16K0F3E @25KHz/
11K0F3E @12.5KHz
4FSK Digital Modulation 12.5KHz(data only):7K60FXD
12.5KHz(data+voice):7K60FXE
Audio Distortion ≤3% @ 40% Deviation
Audio Response +1 ~ -3dB
FM Hum and Noise 40dB @ 12.5KHz / 45dB @ 25KHz
Spurious Emission ≤-36dBm (9KHz~1GHz)
≤-30dBm (1GHz~12.75GHz)


Note: The above specifications are tested in accordance with applicable standards. Due to the continuous development of technology, the above indicators are subject to change without prior notice.


Product Details:

IP68 Waterproof and Dust-tight Build

The M4 is IP68 dust and waterproof, this rugged construction provides dust-tight protection making it suitable for outdoor use.

TDMA 2-Slot

The free slot can be allocated to enhance frequency efficiency and timely response under emergency.

Advanced encryption:

Adopts AES256 encryption to secure communication privacy and optimize information safety.

Analog and Digital Operation

Communicate effortlessly in a mixed group of analog and digital radios, automatically switching with no user intervention.

Loud and Clear Audio

Hear and be heard in noisy environments like construction sites using crystal-clear digital technology and a powerful speaker.

Audio Announcements

Ensure you’re communicating with the intended team by receiving a customizable voice announcement when switching channels.

Our Insepction and Packing Section:

we are committed to delivering top-quality two-way radio products, ensuring each product meets the highest standards through rigorous inspection and packaging processes. Our inspection and packaging team bears the responsibility of ensuring customers receive reliable products, providing a worry-free user experience.

Inspection Process:

1、Visual Inspection: Each two-way radio undergoes a thorough visual inspection to ensure flawless aesthetics that align with the company's brand image.

2、Functionality Testing: Our inspection team conducts comprehensive functionality tests on every radio, ensuring all features operate correctly. This includes key functions such as audio quality, signal strength, and channel switching.

3、Durability Testing: Products undergo durability tests to ensure they function properly in various environmental conditions, including extreme temperatures, humidity, and vibrations.

4、Battery Performance Testing: Battery life is crucial for radio performance. Strict performance tests are conducted on batteries to ensure reliable, extended use.

Packaging Process:

1、Anti-Static Packaging: Each radio undergoes anti-static packaging to prevent electrostatic damage during transportation.

2、Environmentally Friendly Packaging: Committed to sustainability, our packaging materials adhere to international environmental standards.

3、Shock-Resistant Packaging: Professional shock-resistant packaging is employed during transportation to prevent damage to products.

4、Integrity Check: The packaging team performs a final integrity check to ensure products remain intact and undamaged after the packaging process.


Our inspection and packaging processes aim to surpass customer expectations, ensuring that every two-way radio received has undergone rigorous testing and meticulous packaging as a high-quality product.

Explosion Proof Dmr Mobile Radio

Customer Evaluation and Feedback:Satisfied customers are our number one priority
